Jacquard loom Series Specifications | ||||||||||||||
Jacquard needles | 128 | 160 | 192 | 256 | 320 | 384 | 480 | |||||||
Models ( Tapes/Reed width ) | 4/65 6/55 8/30 10/30 8/45 12/25 8/55 10/45 12/30 | 4/65 6/55 8/30 10/30 8/45 12/25 | 4/65 6/55 8/30 10/30 8/45 12/25 | 4/65 6/55 8/30 10/30 8/45 12/25 8/55 10/45 12/30 | 4/65 6/55 8/30 10/30 8/45 12/25 8/55 10/45 12/30 | 4/65 6/55 8/30 10/30 8/45 12/25 8/55 10/45 12/30 | 4/65 6/55 8/30 10/30 8/45 12/25 8/55 10/45 12/30 | |||||||
Motor | 2HP: Double rapid | |||||||||||||
Speed | 800-1000RPM | |||||||||||||
Heald frame | 2-8PCS | |||||||||||||
Design chain circle | 8-40 | |||||||||||||
Weft density | 3.5-36.7 | |||||||||||||
Normal attachment | 14-30 Yarn creel places,Software,Jacquard Normal attachment | |||||||||||||
Optional attachment | Rubber feeder.Double nook single needle system,Beam,Frequency conversion timina,CAD platesoft | |||||||||||||
